M/V Voyager is a multipurpose vessel designed to meet high demands of transferring and cargo loading.
The Volvo Penta D13-800 MCC engines are IMO TIER 3 compliant for reduced NOx emission levels. She has a comfortable passenger saloon with capacity of 12 passengers. Besides the large room for passengers M/V Voyager can take cargo up to 5 tons.
Overview
| Built 2008: | Hull 008, South Boats Special Projects Ltd. Isle of Wig ht, UK |
|---|---|
| Class notification: | Danish Maritime Authority (DMA) cargo ship notice F, UK Designed In accordance with Lloyds Rules for Special Service Craft |
Vessel Specification
Specification
| Trading area: | World wide |
|---|---|
| Call Sign: | OXVM2 |
| Complement total: | 12 Pax + Crew |
| Gross tonnage: | 30 t |
| Net tonnage: | 9 t |
| Hull: | Aluminium |
| Displacement (light ship): | 23 t |
| Length o. a. : | 15,5 m |
| Breadth: | 6,3 m |
| Operational Draught: | 0,95 m |
| Bunker capacity, diesel oil: | 3600 liters |
| Fresh water capacity: | 215 liters |
| Forward deck area: | 12,65 m² |
| Aft deck area: | 18,7 m² |
| After deck dimensions: | 3,4 x 5,5 m |
| Forward deck dimensions: | 2,3 x 5,5 m |
Cargo handling
| Max cargo capacity on deck: | 5 t |
|---|---|
| Deck crane: | One |
| Model: | Palfinger PK4501M |
| Max lifting capacity: | 3200 kg |
| Max lifting capacity @ max outreach: | 200 kg @ 12,5 m |
| Max winch capacity: | 1,5 t |
MAIN AND AUXILARY MACHINERY
| Main engines: | 2 x Volvo Penta D13-800 MCC |
|---|---|
| Power: | 2 x 588/800 kW/HP |
| Propulsion type: | Water jet |
| Propulsion equipment: | Twindisc MGX5135SC / Ultra Dynamics UJ451 |
| Auxiliary engine: | Cummins Onan |
| Output: | 7 kVA 220V |
NAVIGATION AND COMMUNICATION EQUIPMENT
| Radar: | 2 x Furuno navnet GD-1920C-BB |
|---|---|
| El. chart system: | MaxSea/Transas Navisailor / 2 x Furuno Navnet C-map |
| AIS: | Furuno FA-150 Class A |
| GMDSS | A1 |
| Heading system: | Furuno Satellite Compass SC-50 |
| GPS/DGPS: | Furuno GP-150 |
| Autopilot: | Furuno Navpilot 500 |
| Depth sounder: | Furuno FCV-620 |
| Crew finder: | Taiyo Musen TDL1550 VHF DF Reciever |
| Navtex | Furuno Navnet |
Summary
M/V Voyager is a multipurpose vessel designed to meet high demands of transferring and cargo loading. She has a comfortable passenger saloon. Capacity of 12 passengers.
Besides large room for passengers Voyager can take cargo up to 5 tons.
